Cast Iron Sleeves

Cast iron replacement sleeves in a range of bore sizes and lengths. 23 ManuMark cast iron sleeves are listed below, including MM3191-1, MM3191-10, MM3191-11.

Cast Iron Sleeves components manufactured by Pitchline Engineering for ManuMark

Cast Iron Sleeves

The ManuMark sleeve range covers cast iron replacement sleeves for heavy-vehicle hydraulic and pneumatic units. Each listing identifies its inside diameter, outside diameter and length so workshops can match the required component accurately.

  • 23 listed kits and components in this category
  • Rubber parts moulded in-house in nitrile, EPDM, Viton or silicone to suit the fluid
  • Pistons, shafts and adaptors machined on our own CNC lathes and mills
  • Held in stock for ManuMark under JIT flexible manufacturing

Cast Iron Sleeves part list

Quote the ManuMark (MM) part number when you enquire. The catalogue carries the original valve numbers and alternate part numbers for each line.

Part no.ProductReferencesCatalogue page
MM3191-1Cast Iron Sleeve — HSCI 1375/1590Size: 1 3/8" Inside diameter: 34.93 Outside diameter: 40.3 Length: 139.7108
MM3191-10Cast Iron Sleeve — HSCI 1870/2090Size: 47.5 mm Inside diameter: 47.50 Outside diameter: 53 Length: 152.4108
MM3191-11Cast Iron Sleeve — HSCI 1875/2090Size: 1 7/8" Inside diameter: 47.63 Outside diameter: 53 Length: 152.4108
MM3191-12Cast Iron Sleeve — HSCI 2000/2225Size: 2" Inside diameter: 50.80 Outside diameter: 56.4 Length: 139.7108
MM3191-13Cast Iron Sleeve — HSCI 2106/2277Size: 53.5 mm Inside diameter: 53.50 Outside diameter: 57.8 Length: 139.7108
MM3191-14Cast Iron Sleeve — HSCI 2187/2360Size: 2 3/16" Inside diameter: 55.55 Outside diameter: 60 Length: 152.4108
MM3191-15Cast Iron SleeveSize: 44 mm Inside diameter: 44.00 Outside diameter: 53 Length: 152.4108
MM3191-16Cast Iron SleeveSize: 1 7/16" Inside diameter: 36.50 Outside diameter: 42.00 Length: 139.7108
MM3191-17Cast Iron SleeveSize: 2 1/8" Inside diameter: 53.97 Outside diameter: 48.90 Length: 143.0108
MM3191-18Cast Iron SleeveSize: 33 mm Inside diameter: 33.00 Outside diameter: 35.65 Length: 153.0108
MM3191-19Cast Iron SleeveSize: 36 mm Inside diameter: 25.00 Outside diameter: 36.00 Length: 110.0108
MM3191-2Cast Iron Sleeve — HSCI 1437/1590Size: 1 7/16" Inside diameter: 36.50 Outside diameter: 40.3 Length: 139.7108
MM3191-21Cast Iron SleeveSize: 46.8 mm Inside diameter: 44.45 Outside diameter: 46.80 Length: 201.50108
MM3191-22Cast Iron SleeveSize: 45.1 mm Inside diameter: 36.50 Outside diameter: 45.10 Length: 120.0108
MM3191-23Cast Iron SleeveSize: 43.5 mm Inside diameter: 38.10 Outside diameter: 43.50 Length: 201.50108
MM3191-24Cast Iron SleeveSize: 45.1 mm Inside diameter: 36.50 Outside diameter: 45.10 Length: 140.0108
MM3191-3Cast Iron Sleeve — HSCI 1500/1715Size: 1 1/2" Inside diameter: 38.10 Outside diameter: 43.5 Length: 139.7108
MM3191-4Cast Iron Sleeve — HSCI 1575/1777Size: 40 mm Inside diameter: 40.00 Outside diameter: 45.1 Length: 139.7108
MM3191-5Cast Iron Sleeve — HSCI 1625/1840Size: 1 5/8" Inside diameter: 41.28 Outside diameter: 46.7 Length: 139.7108
MM3191-6Cast Iron Sleeve — HSCI 1687/1840Size: 1 11/16" Inside diameter: 72.85 Outside diameter: 46.7 Length: 139.7108
MM3191-7Cast Iron Sleeve — HSCI 1720/1965Size: 1.720" Inside diameter: 43.69 Outside diameter: 49.7 Length: 114.3108
MM3191-8Cast Iron Sleeve — HSCI 1732/1965Size: 44 mm Inside diameter: 44.00 Outside diameter: 49.7 Length: 139.7108
MM3191-9Cast Iron Sleeve — HSCI 1750/1965Size: 1 3/4" Inside diameter: 44.45 Outside diameter: 49.7 Length: 139.7108
